Please send RFQ , we will respond immediately.
| Part Number | NL17SG14P5T5G | NL17SH14P5T5G | NL17SZ14P5T5G | NL17SG04P5T5G |
|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Obsolete | Obsolete | Active |
| Logic Type | - | Inverter | Inverter | Inverter |
| Number of Circuits | - | 1 | 1 | 1 |
| Number of Inputs | - | 1 | 1 | 1 |
| Features | - | Schmitt Trigger | Schmitt Trigger | - |
| Voltage - Supply | - | 1.65V ~ 5.5V | 1.65V ~ 5.5V | 0.9V ~ 3.6V |
| Current - Quiescent (Max) | - | 1 µA | 1 µA | 500 nA |
| Current - Output High, Low | - | 8mA, 8mA | 32mA, 32mA | 8mA, 8mA |
| Logic Level - Low | - | 0.9V ~ 1.65V | 0.2V ~ 1.2V | 0.7V ~ 0.8V |
| Logic Level - High | - | 2.2V ~ 3.85V | 1.4V ~ 3.6V | 1.7V ~ 2V |
| Max Propagation Delay @ V, Max CL | - | 10.6ns @ 5V, 50pF | 5.9ns @ 5V, 50pF | 4.4ns @ 3.3V, 30pF |
| Operating Temperature | - | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Mounting Type | - | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | - | SOT-953 | SOT-953 | SOT-953 |
| Package / Case | - | SOT-953 | SOT-953 | SOT-953 |
