| Part Number | NCV8187AMLE180TCG | NCV8187AMLE280TCG |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Active |
| Output Configuration | Positive | Positive |
| Output Type | Fixed | Fixed |
| Number of Regulators | 1 | 1 |
| Voltage - Input (Max) | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 1.8V | 2.8V |
| Voltage - Output (Max) | - | - |
| Voltage Dropout (Max) | 0.335V @ 1.2A | 0.25V @ 1.2A |
| Current - Output | 1.2A | 1.2A |
| Current - Quiescent (Iq) | 45 µA | 45 µA |
| Current - Supply (Max) | - | - |
| PSRR | 75dB (1kHz) | 75dB (1kHz) |
| Control Features | Enable, Power Good | Enable, Power Good |
| Protection Features | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Surface Mount, Wettable Flank | Surface Mount, Wettable Flank |
| Package / Case | 8-VDFN Exposed Pad | 8-VDFN Exposed Pad |
| Supplier Device Package | 8-DFNW (3x3) | 8-DFNW (3x3) |
