Please send RFQ , we will respond immediately.
| Part Number | NCV8177AMX150TCG | NCV8177AMX180TCG | NCV8177AMX250TCG | NCV8177BMX150TCG | NCV8170AMX150TCG | NCV8177AMX120TCG |
|---|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Active | Active | Active | Active |
| Output Configuration | - | Positive | Positive | Positive | Positive | Positive |
| Output Type | - | Fixed | Fixed | Fixed | Fixed | Fixed |
| Number of Regulators | - | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input (Max) | - | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | - | 1.8V | 2.5V | 1.5V | 1.5V | 1.2V |
| Voltage - Output (Max) | - | - | - | - | - | - |
| Voltage Dropout (Max) | - | 0.35V @ 500mA | 0.26V @ 500mA | 0.41V @ 500mA | - | - |
| Current - Output | - | 500mA | 500mA | 500mA | 150mA | 500mA |
| Current - Quiescent (Iq) | - | 90 µA | 90 µA | 90 µA | 0.9 µA | 90 µA |
| Current - Supply (Max) | - | - | - | - | - | - |
| PSRR | - | 75dB (1kHz) | 75dB (1kHz) | 75dB (1kHz) | 57dB (1kHz) | 75dB (1kHz) |
| Control Features | - | Enable | Enable | Enable | Enable | Enable |
| Protection Features | - | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | - | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C | -40°C ~ 125°C (TA) |
| Mounting Type | - | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | - | 4-XDFN Exposed Pad | 4-XDFN Exposed Pad | 4-XDFN Exposed Pad | 4-XDFN Exposed Pad | 4-XDFN Exposed Pad |
| Supplier Device Package | - | 4-XDFN (1x1) | 4-XDFN (1x1) | 4-XDFN (1x1) | 4-XDFN (1x1) | 4-XDFN (1x1) |
