| Part Number | NCV8135AMTW040TBG | NCV8135BMTW040TBG | NCV8135AMT040TBG |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Active |
| Output Configuration | - | Positive | Positive |
| Output Type | - | Fixed | Fixed |
| Number of Regulators | - | 1 | 1 |
| Voltage - Input (Max) | - | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | - | 0.4V | 0.4V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | - | 0.1V @ 500mA | 0.1V @ 500mA |
| Current - Output | - | 500mA | 500mA |
| Current - Quiescent (Iq) | - | 55 µA | 55 µA |
| Current - Supply (Max) | - | - | - |
| PSRR | - | 73dB (1kHz) | 73dB ~ 90dB (1kHz) |
| Control Features | - | Enable | Enable |
| Protection Features | - | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | - | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | - | Surface Mount | Surface Mount |
| Package / Case | - | 6-WDFN Exposed Pad | 6-WDFN Exposed Pad |
| Supplier Device Package | - | 6-WDFN (2x2) | 6-WDFN (2x2) |
