| Part Number | NCV8133BMX150TCG | NCV8133BMX180TCG | NCV8130BMX150TCG | NCV8133BMX100TCG | NCV8133BMX110TCG | NCV8133BMX120TCG | NCV8133BMX130TCG |
|---|---|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Obsolete | Active | Active | Active | Active | Active |
| Output Configuration | - | Positive | Positive | Positive | Positive | Positive | - |
| Output Type | - | Fixed | Fixed | Fixed | Fixed | Fixed | - |
| Number of Regulators | - | 1 | 1 | 1 | 1 | 1 | - |
| Voltage - Input (Max) | - | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | - |
| Voltage - Output (Min/Fixed) | - | 1.8V | 1.5V | 1V | 1.1V | 1.2V | - |
| Voltage - Output (Max) | - | - | - | - | - | - | - |
| Voltage Dropout (Max) | - | 0.3V @ 500mA | 0.175V @ 300mA | 0.3V @ 500mA | 0.3V @ 500mA | 0.3V @ 500mA | - |
| Current - Output | - | 500mA | 300mA | 500mA | 500mA | 500mA | - |
| Current - Quiescent (Iq) | - | - | - | - | - | - | - |
| Current - Supply (Max) | - | - | - | - | - | - | - |
| PSRR | - | 70dB (1kHz) | 65dB (1kHz) | 70dB (1kHz) | 70dB (1kHz) | 70dB (1kHz) | - |
| Control Features | - | Enable | Enable | Enable | Enable | Enable | - |
| Protection Features | - | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | - |
| Operating Temperature | - | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | - |
| Mounting Type | - | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | - |
| Package / Case | - | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | - |
| Supplier Device Package | - | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | - |
