| Part Number | NCV8130BMX130TCG | NCV8133BMX130TCG | NCV8130BMX150TCG | NCV8130BMX180TCG | NCV8130BMX100TCG | NCV8130BMX110TCG | NCV8130BMX120TCG |
|---|---|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Active | Active | Active | Active | Active |
| Output Configuration | - | - | Positive | Positive | Positive | Positive | Positive |
| Output Type | - | - | Fixed | Fixed | Fixed | Fixed | Fixed |
| Number of Regulators | - | - | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input (Max) | - | - | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | - | - | 1.5V | 1.8V | 1V | 1.1V | 1.2V |
| Voltage - Output (Max) | - | - | - | - | - | - | - |
| Voltage Dropout (Max) | - | - | 0.175V @ 300mA | 0.175V @ 300mA | 0.175V @ 300mA | 0.175V @ 300mA | 0.175V @ 300mA |
| Current - Output | - | - | 300mA | 300mA | 300mA | 300mA | 300mA |
| Current - Quiescent (Iq) | - | - | - | - | - | - | - |
| Current - Supply (Max) | - | - | - | - | - | - | - |
| PSRR | - | - | 65dB (1kHz) | 65dB (1kHz) | 65dB (1kHz) | 65dB (1kHz) | 65dB (1kHz) |
| Control Features | - | - | Enable | Enable | Enable | Enable | Enable |
| Protection Features | - | - | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | - | - | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | - | - | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | - | - | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad | 6-XFDFN Exposed Pad |
| Supplier Device Package | - | - | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) | 6-XDFN (1.2x1.2) |
