| Part Number | NCS199A1RSQT2G | NCS199A3RSQT2G | NCS199A2RSQT2G | NCS199A1SQT2G |
|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Active | Obsolete |
| Amplifier Type | Current Sense | Current Sense | Current Sense | Current Sense |
| Number of Circuits | 1 | 1 | 1 | 1 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 1V/µs | 1V/µs | 1V/µs | 0.4V/µs |
| Gain Bandwidth Product | - | - | - | - |
| -3db Bandwidth | 90 kHz | 40 kHz | 60 kHz | 100 kHz |
| Current - Input Bias | 39 µA | 39 µA | 39 µA | 60 µA |
| Voltage - Input Offset | 5 µV | 5 µV | 5 µV | 5 µV |
| Current - Supply | 40µA | 40µA | 40µA | 65µA |
| Current - Output / Channel | - | - | - | - |
| Voltage - Supply Span (Min) | 2.2 V | 2.2 V | 2.2 V | 2.7 V |
| Voltage - Supply Span (Max) | 26 V | 26 V | 26 V | 26 V |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 | 6-TSSOP, SC-88, SOT-363 | 6-TSSOP, SC-88, SOT-363 | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SC-88/SC70-6/SOT-363 | SC-88/SC70-6/SOT-363 | SC-88/SC70-6/SOT-363 | SC-88/SC70-6/SOT-363 |
