Please send RFQ , we will respond immediately.
| Part Number | NCP7805TG | NCP7808TG | NCP7815TG | NCP7805CTG | NCP7805ETG |
|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Obsolete | Obsolete | Obsolete | Obsolete |
| Output Configuration | Positive | Positive | Positive | Positive | Positive |
| Output Type | Fixed | Fixed | Fixed | Fixed | Fixed |
| Number of Regulators | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input (Max) | 35V | 35V | 35V | 25V | 35V |
| Voltage - Output (Min/Fixed) | 5V | 8V | 15V | 5V | 5V |
| Voltage - Output (Max) | - | - | - | - | - |
| Voltage Dropout (Max) | 2V @ 1A (Typ) | 2V @ 1A (Typ) | 2V @ 1A (Typ) | 2V @ 1A (Typ) | 2V @ 1A (Typ) |
| Current - Output | 1A | 1A | 1A | 1A | 1A |
| Current - Quiescent (Iq) | 8 mA | 8 mA | 8 mA | 8 mA | 8 mA |
| Current - Supply (Max) | - | - | - | - | - |
| PSRR | 75dB (120Hz) | 72dB (120Hz) | 70dB (120Hz) | 75dB (120Hz) | 75dB (120Hz) |
| Control Features | - | - | - | - | - |
| Protection Features | Over Temperature, Short Circuit | Over Temperature, Short Circuit | Over Temperature, Short Circuit | Over Temperature, Short Circuit | Over Temperature, Short Circuit |
| Operating Temperature | 0°C ~ 125°C (TJ) | 0°C ~ 125°C (TJ) | 0°C ~ 125°C (TJ) | 0°C ~ 125°C (TJ) | 0°C ~ 125°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-220-3 | TO-220-3 | TO-220-3 | TO-220-3 | TO-220-3 |
| Supplier Device Package | TO-220 | TO-220 | TO-220 | TO-220AB | TO-220 |
