| Part Number | NCP6336BFCCT1G | NCP6336FCCT1G | NCP6335BFCCT1G |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete |
| Function | - | Step-Down | Step-Down |
| Output Configuration | - | Positive | Positive |
| Topology | - | Buck | Buck |
| Output Type | - | Programmable | Programmable |
| Number of Outputs | - | 1 | 1 |
| Voltage - Input (Min) | - | 2.3V | 2.3V |
| Voltage - Input (Max) | - | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | - | 0.6V | 0.6V |
| Voltage - Output (Max) | - | 1.5V | 1.4V |
| Current - Output | - | 500mA | 4A |
| Frequency - Switching | - | 3MHz | 3MHz |
| Synchronous Rectifier | - | Yes | Yes |
| Operating Temperature | - | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 20-UFBGA, WLCSP | 20-UFBGA, WLCSP | 20-UFBGA, WLCSP |
| Supplier Device Package | 20-WLCSP (1.62x2.02) | 20-WLCSP (1.62x2.02) | 20-WLCSP (1.62x2.02) |
