| Part Number | NCP186BMX280TAG | NCP186AMX280TAG | NCP186BMX180TAG | NCP186BMX250TAG |
|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Active | Active | Active |
| Output Configuration | Positive | Positive | Positive | - |
| Output Type | Fixed | Fixed | Fixed | - |
| Number of Regulators | 1 | 1 | 1 | - |
| Voltage - Input (Max) | 5.5V | 5.5V | 5.5V | - |
| Voltage - Output (Min/Fixed) | 2.8V | 2.8V | 1.8V | - |
| Voltage - Output (Max) | - | - | - | - |
| Voltage Dropout (Max) | 0.17V @ 1A | 0.17V @ 1A | 0.285V @ 1A | - |
| Current - Output | 1A | 1A | 1A | - |
| Current - Quiescent (Iq) | 140 µA | 140 µA | 140 µA | - |
| Current - Supply (Max) | - | - | - | - |
| PSRR | 75dB (1kHz) | 75dB (1kHz) | 75dB (1kHz) | - |
| Control Features | Enable | Enable | Enable | - |
| Protection Features | Over Current, Over Temperature, Soft Start | Over Current, Over Temperature, Soft Start | Over Current, Over Temperature, Soft Start | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | - |
| Package / Case | 8-XFDFN Exposed Pad | 8-XFDFN Exposed Pad | 8-XFDFN Exposed Pad | - |
| Supplier Device Package | 8-XDFN (1.6x1.2) | 8-XDFN (1.6x1.2) | 8-XDFN (1.6x1.2) | - |
