| Part Number | NCP163BMX1825TBG | NCP163AMX1825TBG |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Active |
| Output Configuration | Positive | Positive |
| Output Type | Fixed | Fixed |
| Number of Regulators | 1 | 1 |
| Voltage - Input (Max) | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 1.825V | 1.825V |
| Voltage - Output (Max) | - | - |
| Voltage Dropout (Max) | - | - |
| Current - Output | 250mA | 250mA |
| Current - Quiescent (Iq) | 20 µA | 20 µA |
| Current - Supply (Max) | - | - |
| PSRR | 91dB ~ 60dB (100Hz ~ 100kHz) | 91dB ~ 60dB (100Hz ~ 100kHz) |
| Control Features | Enable | Enable |
| Protection Features | Over Current, Over Temperature, Soft Start | Over Current, Over Temperature, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 4-XDFN Exposed Pad | 4-XDFN Exposed Pad |
| Supplier Device Package | 4-XDFN (1x1) | 4-XDFN (1x1) |
