| Part Number | NCP148AFCT250T2G | NCP148AFCT260T2G | NCP148AFCT270T2G | NCP148AFCT280T2G |
|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Active | Active |
| Output Configuration | - | Positive | Positive | Positive |
| Output Type | - | Fixed | Fixed | Fixed |
| Number of Regulators | - | 1 | 1 | 1 |
| Voltage - Input (Max) | - | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | - | 2.6V | 2.7V | 2.8V |
| Voltage - Output (Max) | - | - | - | - |
| Voltage Dropout (Max) | - | - | 0.3V @ 450mA | 0.29V @ 450mA |
| Current - Output | - | 450mA | 450mA | 450mA |
| Current - Quiescent (Iq) | - | 65 µA | 65 µA | 65 µA |
| Current - Supply (Max) | - | - | - | - |
| PSRR | - | 91dB ~ 48dB (100Hz ~ 100kHz) | 91dB ~ 48dB (100Hz ~ 100kHz) | 91dB ~ 48dB (100Hz ~ 100kHz) |
| Control Features | - | Enable | Enable | Enable |
| Protection Features | - | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | - | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | - | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | - | 4-XFBGA, WLCSP | 4-XFBGA, WLCSP | 4-XFBGA, WLCSP |
| Supplier Device Package | - | 4-WLCSP (0.64x0.64) | 4-WLCSP (0.64x0.64) | 4-WLCSP (0.64x0.64) |
