| Part Number | MZP4734ARL | MZP4737ARL | MZP4734ARLG | MZP4735ARL |
|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Obsolete | Obsolete |
| Voltage - Zener (Nom) (Vz) | 5.6 V | 10 V | 5.6 V | 6.2 V |
| Tolerance | ±5% | ±5% | ±5% | ±5% |
| Power - Max | 3 W | 3 W | 3 W | 3 W |
| Impedance (Max) (Zzt) | 5 Ohms | 7 Ohms | 5 Ohms | 2 Ohms |
| Current - Reverse Leakage @ Vr | 10 µA @ 2 V | 10 µA @ 7.6 V | 10 µA @ 2 V | 10 µA @ 3 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA | 1.5 V @ 200 mA | 1.5 V @ 200 mA | 1.5 V @ 200 mA |
| Operating Temperature | -65°C ~ 200°C | -65°C ~ 200°C | -65°C ~ 200°C | -65°C ~ 200°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | Axial | Axial | Axial | Axial |
