| Part Number | MURF860G | MUR860G | MURF860 |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | SMC Diode Solutions |
| Product Status | Active | Active | Obsolete |
| Diode Type | Standard | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600 V | 600 V | 600 V |
| Current - Average Rectified (Io) | 8A | 8A | 8A |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 8 A | 1.5 V @ 8 A | 2.2 V @ 8 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 60 ns | 60 ns | 50 ns |
| Current - Reverse Leakage @ Vr | 10 µA @ 600 V | 10 µA @ 600 V | 5 µA @ 600 V |
| Capacitance @ Vr, F | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-220-2 Full Pack | TO-220-2 | TO-220-2 Full Pack, Isolated Tab |
| Supplier Device Package | TO-220FP | TO-220-2 | ITO-220AC |
| Operating Temperature - Junction | -65°C ~ 175°C | -65°C ~ 175°C | -55°C ~ 150°C |
