Please send RFQ , we will respond immediately.
| Part Number | MPSW06RLRA | MPSW56RLRA | MPSW06RLRAG |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete |
| Transistor Type | - | PNP | NPN |
| Current - Collector (Ic) (Max) | - | 500 mA | 500 mA |
| Voltage - Collector Emitter Breakdown (Max) | - | 80 V | 80 V |
| Vce Saturation (Max) @ Ib, Ic | - | 500mV @ 10mA, 250mA | 400mV @ 10mA, 250mA |
| Current - Collector Cutoff (Max) | - | 500nA | 500nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | - | 50 @ 250mA, 1V | 60 @ 250mA, 1V |
| Power - Max | - | 1 W | 1 W |
| Frequency - Transition | - | 50MHz | 50MHz |
| Operating Temperature | - | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | - | Through Hole | Through Hole |
| Package / Case | - | TO-226-3, TO-92-3 Long Body (Formed Leads) | TO-226-3, TO-92-3 Long Body (Formed Leads) |
| Supplier Device Package | - | TO-92 (TO-226) | TO-92 (TO-226) |
