| Part Number | MMSZ4697T1 | MMSZ4697T1G | MMSZ4699T1 | MMSZ4698T1 | MMSZ4690T1 | MMSZ4691T1 | MMSZ4692T1 | MMSZ4693T1 | MMSZ4694T1 | MMSZ4695T1 | MMSZ4696T1 | MMSZ4697ET1 | MMSZ4697T |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | Fairchild Semiconductor | onsemi | onsemi | onsemi | onsemi | Rectron USA |
| Product Status | Obsolete | Active | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Active |
| Voltage - Zener (Nom) (Vz) | 10 V | 10 V | 12 V | 11 V | 5.6 V | 6.2 V | 6.8 V | 7.5 V | 8.2 V | 8.7 V | 9.1 V | 10 V | 10 V |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% |
| Power - Max | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 500 mW | 300 mW |
| Impedance (Max) (Zzt) | - | - | - | - | - | - | - | - | - | - | - | - | - |
| Current - Reverse Leakage @ Vr | 1 µA @ 7.6 V | 1 µA @ 7.6 V | 50 nA @ 9.1 V | 50 nA @ 8.4 V | 10 µA @ 4 V | 10 µA @ 5 V | 10 µA @ 5.1 V | 10 µA @ 5.7 V | 1 µA @ 6.2 V | 1 µA @ 6.6 V | 1 µA @ 6.9 V | 1 µA @ 7.6 V | 1 µA @ 7.6 V |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA |
| Operating Temperature | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 120°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C (TJ) | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SC-79, SOD-523 |
| Supplier Device Package | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-123 | SOD-523 |
