| Part Number | MC74HC173N | MC74HC175N |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Active |
| Function | Master Reset | Master Reset |
| Type | D-Type | D-Type |
| Output Type | Tri-State, Non-Inverted | Complementary |
| Number of Elements | 1 | 1 |
| Number of Bits per Element | 4 | 4 |
| Clock Frequency | 60 MHz | 35 MHz |
| Max Propagation Delay @ V, Max CL | 34ns @ 6V, 50pF | 22ns @ 6V, 50pF |
| Trigger Type | Positive Edge | Positive Edge |
| Current - Output High, Low | 7.8mA, 7.8mA | 5.2mA, 5.2mA |
| Voltage - Supply | 2V ~ 6V | 2V ~ 6V |
| Current - Quiescent (Iq) | 8 µA | 4 µA |
| Input Capacitance | 10 pF | 10 pF |
| Operating Temperature | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole | Through Hole |
| Supplier Device Package | 16-PDIP | 16-PDIP |
| Package / Case | 16-DIP (0.300", 7.62mm) | 16-DIP (0.300", 7.62mm) |
