Please send RFQ , we will respond immediately.
| Part Number | MC34071PG | MC34074PG | MC34072PG | MC34071APG | MC34071DG | MC34071P |
|---|---|---|---|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor | onsemi | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Amplifier Type | General Purpose | J-FET | J-FET | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 1 | 4 | 2 | 1 | 1 | 1 |
| Output Type | - | - | Differential | - | - | - |
| Slew Rate | 13V/µs | 13V/µs | 13V/µs | 13V/µs | 13V/µs | 13V/µs |
| Gain Bandwidth Product | 4.5 MHz | 4.5 MHz | 4.5 MHz | 4.5 MHz | 4.5 MHz | 4.5 MHz |
| -3db Bandwidth | - | - | - | - | - | - |
| Current - Input Bias | 100 nA | 100 nA | 100 nA | 100 nA | 100 nA | 100 nA |
| Voltage - Input Offset | 1 mV | 1 mV | 1 mV | 500 µV | 1 mV | 1 mV |
| Current - Supply | 1.9mA | 1.9mA (x4 Channels) | 1.9mA (x2 Channels) | 1.9mA | 1.9mA | 1.9mA |
| Current - Output / Channel | 30 mA | 30 mA | 30 mA | 30 mA | 30 mA | 30 mA |
| Voltage - Supply Span (Min) | 3 V | 3 V | 3 V | 3 V | 3 V | 3 V |
| Voltage - Supply Span (Max) | 44 V | 44 V | 44 V | 44 V | 44 V | 44 V |
| Operating Temperature | 0°C ~ 70°C | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Surface Mount | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) | 14-DIP (0.300", 7.62mm) | 8-DIP (0.300", 7.62mm) | 8-DIP (0.300", 7.62mm) | 8-SOIC (0.154", 3.90mm Width) | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP | 14-PDIP | 8-PDIP | 8-PDIP | 8-SOIC | 8-PDIP |
