| Part Number | MAN8640 | MAN8610 |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Obsolete | Obsolete |
| Display Format | - | - |
| Number of Characters | 1 | 1 |
| Size / Dimension | 0.985" H x 0.735" W x 0.415" D (25.02mm x 18.67mm x 10.54mm) | 0.985" H x 0.735" W x 0.415" D (25.02mm x 18.67mm x 10.54mm) |
| Digit/Alpha Size | 0.80" (20.32mm) | 0.80" (20.32mm) |
| Display Type | 7-Segment | 7-Segment |
| Common Pin | Common Cathode | Common Anode |
| Color | Orange-Red | Orange-Red |
| Voltage - Forward (Vf) (Typ) | 2.5V (Max) | 2.5V (Max) |
| Current - Test | 20mA | 20mA |
| Millicandela Rating | 2.2mcd | 2.2mcd |
| Wavelength - Peak | 630nm | 630nm |
| Power Dissipation (Max) | 600mW | 600mW |
| Package / Case | 18-DIP (0.600", 15.24mm), 14 Leads | 18-DIP (0.600", 15.24mm), 14 Leads |
