| Part Number | LM201ANG | LM201ADG | LM201AN |
|---|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor | STMicroelectronics |
| Product Status | Obsolete | Obsolete | Obsolete |
| Amplifier Type | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 1 | 1 | 1 |
| Output Type | - | - | - |
| Slew Rate | 0.5V/µs | 10V/µs | 0.5V/µs |
| Gain Bandwidth Product | 1 MHz | - | 1 MHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 30 nA | 30 nA | 25 nA |
| Voltage - Input Offset | 700 µV | 700 µV | 700 µV |
| Current - Supply | 1.8mA | 1.8mA | 1.8mA |
| Current - Output / Channel | - | - | 30 mA |
| Voltage - Supply Span (Min) | 10 V | 10 V | 10 V |
| Voltage - Supply Span (Max) | 44 V | 44 V | 44 V |
| Operating Temperature | -25°C ~ 85°C | -25°C ~ 85°C | -40°C ~ 105°C |
| Mounting Type | Through Hole | Surface Mount | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) | 8-SOIC (0.154", 3.90mm Width) | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP | 8-SOIC | 8-DIP |
