| Part Number | GBU8A | GBU8J | GBU8B | GBU8D | GBU8K | GBU6A |
|---|---|---|---|---|---|---|
| Manufacturer | onsemi | GeneSiC Semiconductor | GeneSiC Semiconductor | GeneSiC Semiconductor | onsemi | onsemi |
| Product Status | Active | Active | Active | Active | Active | Active |
| Diode Type | Single Phase | Single Phase | Single Phase | Single Phase | Single Phase | Single Phase |
| Technology | Standard | Standard | Standard | Standard | Standard | Standard |
| Voltage - Peak Reverse (Max) | 50 V | 600 V | 100 V | 200 V | 800 V | 50 V |
| Current - Average Rectified (Io) | 8 A | 8 A | 8 A | 8 A | 8 A | 6 A |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 8 A | 1.1 V @ 8 A | 1.1 V @ 8 A | 1.1 V @ 8 A | 1 V @ 8 A | 1 V @ 6 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 50 V | 5 µA @ 600 V | 5 µA @ 100 V | 5 µA @ 200 V | 5 µA @ 800 V | 5 µA @ 50 V |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | 4-SIP, GBU | 4-SIP, GBU | 4-SIP, GBU | 4-SIP, GBU | 4-SIP, GBU | 4-SIP, GBU |
| Supplier Device Package | GBU | GBU | GBU | GBU | GBU | GBU |
