| Part Number | FSUSB30L10X | FSUSB40L10X | FSUSB20L10X |
|---|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor | Fairchild Semiconductor |
| Product Status | Last Time Buy | Active | Obsolete |
| Applications | USB | USB | USB |
| Multiplexer/Demultiplexer Circuit | - | - | - |
| Switch Circuit | DPDT | DPDT | DPDT |
| Number of Channels | 1 | 1 | 1 |
| On-State Resistance (Max) | 10Ohm | 6.5Ohm | 6.5Ohm |
| Voltage - Supply, Single (V+) | 3V ~ 4.3V | 3V ~ 4.3V | 3V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - | - | - |
| -3db Bandwidth | 720MHz | 720MHz | 750MHz |
| Features | Break-Before-Make, USB 2.0 | Break-Before-Make, USB 2.0 | Bi-Directional, USB 2.0 |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 10-UFQFN Exposed Pad | 10-UFQFN Exposed Pad | 10-UFQFN Exposed Pad |
| Supplier Device Package | 10-MicroPak™ | 10-MicroPak™ | 10-MicroPak™ |
