| Part Number | FSS273-TL-E | FSS275-TL-E |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Obsolete |
| FET Type | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 45 V | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 8A (Ta) | 6A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - | - |
| Rds On (Max) @ Id, Vgs | 22mOhm @ 8A, 10V | 43mOhm @ 3A, 10V |
| Vgs(th) (Max) @ Id | - | - |
| Gate Charge (Qg) (Max) @ Vgs | 40 nC @ 10 V | 21 nC @ 10 V |
| Vgs (Max) | - | - |
| Input Capacitance (Ciss) (Max) @ Vds | 2225 pF @ 20 V | 1100 pF @ 20 V |
| FET Feature | - | - |
| Power Dissipation (Max) | 2.4W (Ta) | 1.9W (Ta) |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | 8-SOP | 8-SOP |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) | 8-SOIC (0.173", 4.40mm Width) |
