Please send RFQ , we will respond immediately.
| Part Number | FSL538HPG | FSL518HPG | FSL538APG |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Active | Active | Active |
| Output Isolation | Either | Either | - |
| Internal Switch(s) | Yes | Yes | - |
| Voltage - Breakdown | 800V | 800V | - |
| Topology | Flyback | Flyback | - |
| Voltage - Start Up | 16 V | 16 V | - |
| Voltage - Supply (Vcc/Vdd) | - | - | - |
| Duty Cycle | - | - | - |
| Frequency - Switching | 130kHz | 130kHz | - |
| Power (Watts) | 21 W | 15 W | - |
| Fault Protection | Current Limiting, Over Load, Over Power, Over Temperature, Over Voltage | Current Limiting, Over Load, Over Power, Over Temperature, Over Voltage | - |
| Control Features | EN, Soft Start | EN, Soft Start | - |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | - |
| Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads | 8-DIP (0.300", 7.62mm), 7 Leads | - |
| Supplier Device Package | 7-PDIP | 7-PDIP | - |
| Mounting Type | Through Hole | Through Hole | - |
