onsemi-FOD816300W - Optoisolators - Logic Output Product Specifications and Latest Quotes

Number of Channels:	1
Inputs - Side 1/Side 2:	-
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	-
Input Type:	AC, DC
Output Type:	Darlington
Current - Output / Channel:	80 mA
Data Rate:	-
Propagation Delay tpLH / tpHL (Max):	-
Rise / Fall Time (Typ):	60µs, 53µs
Voltage - Forward (Vf) (Typ):	1.2V
Current - DC Forward (If) (Max):	50mA
Voltage - Supply:	-
Operating Temperature:	-30°C ~ 100°C
Mounting Type:	Through Hole
Package / Case:	4-DIP (0.400", 10.16mm)
Supplier Device Package:	4-DIP

onsemi FOD816300W
