| Part Number | FGA60N65SMD | FGA40N65SMD |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Active |
| IGBT Type | Field Stop | Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 650 V | 650 V |
| Current - Collector (Ic) (Max) | 120 A | 80 A |
| Current - Collector Pulsed (Icm) | 180 A | 120 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 60A | 2.5V @ 15V, 40A |
| Power - Max | 600 W | 349 W |
| Switching Energy | 1.54mJ (on), 450µJ (off) | 820µJ (on), 260µJ (off) |
| Input Type | Standard | Standard |
| Gate Charge | 189 nC | 119 nC |
| Td (on/off) @ 25°C | 18ns/104ns | 12ns/92ns |
| Test Condition | 400V, 60A, 3Ohm, 15V | 400V, 40A, 6Ohm, 15V |
| Reverse Recovery Time (trr) | 47 ns | 42 ns |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-3P-3, SC-65-3 | TO-3P-3, SC-65-3 |
| Supplier Device Package | TO-3P | TO-3PN |
