| Part Number | FFAF60UA60DN | FFA60UA60DN |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Obsolete | Active |
| Diode Configuration | 1 Pair Common Cathode | 1 Pair Common Cathode |
| Diode Type | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600 V | 600 V |
| Current - Average Rectified (Io) (per Diode) | 30A | 30A |
| Voltage - Forward (Vf) (Max) @ If | 2.2 V @ 30 A | 2.2 V @ 30 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 90 ns | 90 ns |
| Current - Reverse Leakage @ Vr | 100 µA @ 600 V | 100 µA @ 600 V |
| Operating Temperature - Junction | -65°C ~ 150°C | -65°C ~ 150°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-3P-3 Full Pack | TO-3P-3, SC-65-3 |
| Supplier Device Package | TO-3PF | TO-3PN |
