| Part Number | FDMC4435BZ | FDMC4436BZ |
|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor |
| Product Status | Active | Obsolete |
| FET Type | P-Channel | - |
| Technology | MOSFET (Metal Oxide) | - |
| Drain to Source Voltage (Vdss) | 30 V | - |
| Current - Continuous Drain (Id) @ 25°C | 8.5A (Ta), 18A (Tc) | - |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | - |
| Rds On (Max) @ Id, Vgs | 20mOhm @ 8.5A, 10V | - |
| Vgs(th) (Max) @ Id | 3V @ 250µA | - |
| Gate Charge (Qg) (Max) @ Vgs | 46 nC @ 10 V | - |
| Vgs (Max) | ±25V | - |
| Input Capacitance (Ciss) (Max) @ Vds | 2045 pF @ 15 V | - |
| FET Feature | - | - |
| Power Dissipation (Max) | 2.3W (Ta), 31W (Tc) | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | - |
| Mounting Type | Surface Mount | - |
| Supplier Device Package | 8-MLP (3.3x3.3) | - |
| Package / Case | 8-PowerWDFN | - |
