| Part Number | FAN48685UC08X | FAN48615UC08X |
|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor |
| Product Status | Active | Active |
| Function | Step-Up | Step-Up |
| Output Configuration | Positive | Positive |
| Topology | Boost | Boost |
| Output Type | Programmable | Fixed |
| Number of Outputs | 1 | 1 |
| Voltage - Input (Min) | 2.5V | 2.7V |
| Voltage - Input (Max) | 5.5V | 4.5V |
| Voltage - Output (Min/Fixed) | 3.6V, 5V, 5.45V | 5.25V |
| Voltage - Output (Max) | - | - |
| Current - Output | 800mA | 1A |
| Frequency - Switching | 2.5MHz | 2.3MHz |
| Synchronous Rectifier | Yes | Yes |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 9-UFBGA, WLCSP | 9-UFBGA, WLCSP |
| Supplier Device Package | 9-WLCSP (1.22x1.22) | 9-WLCSP (1.22x1.22) |
