| Part Number | FAN23SV60AMPX | FAN23SV70AMPX | FAN23SV65AMPX |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Active | Obsolete |
| Function | Step-Down | Step-Down | Step-Down |
| Output Configuration | Positive | Positive | Positive |
| Topology | Buck | Buck | Buck |
| Output Type | Adjustable | Adjustable | Adjustable |
| Number of Outputs | 1 | 1 | 1 |
| Voltage - Input (Min) | 7V | 7V | 7V |
| Voltage - Input (Max) | 24V | 24V | 24V |
| Voltage - Output (Min/Fixed) | 0.6V | 0.6V | 0.6V |
| Voltage - Output (Max) | 5.5V | 5.5V | 5.5V |
| Current - Output | 10A | 20A | 15A |
| Frequency - Switching | 200kHz ~ 1.5MHz | 200kHz ~ 1MHz | 200kHz ~ 1MHz |
| Synchronous Rectifier | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 34-PowerTFQFN | 34-PowerTFQFN | 34-PowerTFQFN |
| Supplier Device Package | 34-PQFN (5.5x5) | 34-PQFN (5.5x5) | 34-PQFN (5.5x5) |
