Please send RFQ , we will respond immediately.
| Part Number | EMH2409-TL-H | EMH2407-TL-H | EMH2408-TL-H |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete |
| FET Type | 2 N-Channel (Dual) | - | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate | - | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V | - | 20V |
| Current - Continuous Drain (Id) @ 25°C | 4A | - | 4A |
| Rds On (Max) @ Id, Vgs | 59mOhm @ 2A, 10V | - | 45mOhm @ 4A, 4.5V |
| Vgs(th) (Max) @ Id | - | - | - |
| Gate Charge (Qg) (Max) @ Vgs | 4.4nC @ 10V | - | 4.7nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 240pF @ 10V | - | 345pF @ 10V |
| Power - Max | 1.2W | - | 1.2W |
| Operating Temperature | 150°C (TJ) | - | 150°C (TJ) |
| Mounting Type | Surface Mount | - | Surface Mount |
| Package / Case | 8-SMD, Flat Lead | - | 8-SMD, Flat Lead |
| Supplier Device Package | 8-EMH | - | 8-EMH |
