Please send RFQ , we will respond immediately.
| Part Number | DSK10E-BT | DSK10G-BT | DSK10B-BT | DSK10C-BT |
|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Active | Obsolete | Obsolete |
| Diode Type | Standard | - | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 400 V | - | 100 V | 200 V |
| Current - Average Rectified (Io) | 1A | - | 1A | 1A |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 1 A | - | 1.1 V @ 1 A | 1.1 V @ 1 A |
| Speed | Standard Recovery >500ns, > 200mA (Io) | - | Standard Recovery >500ns, > 200mA (Io) | Standard Recovery >500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | - | - | - |
| Current - Reverse Leakage @ Vr | 10 µA @ 400 V | - | 10 µA @ 100 V | 10 µA @ 200 V |
| Capacitance @ Vr, F | - | - | - | - |
| Mounting Type | Through Hole | - | Through Hole | Through Hole |
| Package / Case | R-1, Axial | - | Axial | R-1, Axial |
| Supplier Device Package | - | - | - | - |
| Operating Temperature - Junction | 150°C (Max) | - | 150°C (Max) | 150°C (Max) |
