| Part Number | CS51411GMNR2G | CS51412GMNR2G | CS51413GMNR2G | CS51414GMNR2G | CS51411EMNR2G |
|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Function | Step-Down | Step-Down | Step-Down | Step-Down | Step-Down |
| Output Configuration | Positive | Positive | Positive | Positive | Positive |
| Topology | Buck | Buck | Buck | Buck | Buck |
| Output Type | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable |
| Number of Outputs | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input (Min) | 4.5V | 4.5V | 4.5V | 4.5V | 4.5V |
| Voltage - Input (Max) | 40V | 40V | 40V | 40V | 40V |
| Voltage - Output (Min/Fixed) | 1.27V | 1.27V | 1.27V | 1.27V | 1.27V |
| Voltage - Output (Max) | 38V | 38V | 38V | 38V | 38V |
| Current - Output | 1.5A | 1.5A | 1.5A | 1.5A | 1.5A |
| Frequency - Switching | 260kHz | 260kHz | 520kHz | 520kHz | 260kHz |
| Synchronous Rectifier | No | No | No | No | No |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 18-VFDFN Exposed Pad | 18-VFDFN Exposed Pad | 18-VFDFN Exposed Pad | 18-VFDFN Exposed Pad | 18-VFDFN Exposed Pad |
| Supplier Device Package | 18-DFN (5x6) | 18-DFN (5x6) | 18-DFN (5x6) | 18-DFN (5x6) | 18-DFN (5x6) |
