Please send RFQ , we will respond immediately.
| Part Number | BYW80-200 | BYW80-200G |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Obsolete | Active |
| Diode Type | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 200 V | 200 V |
| Current - Average Rectified (Io) | 10A | 8A |
| Voltage - Forward (Vf) (Max) @ If | 1.15 V @ 15 A | 1.25 V @ 22 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 35 ns | 35 ns |
| Current - Reverse Leakage @ Vr | 10 µA @ 200 V | 10 µA @ 200 V |
| Capacitance @ Vr, F | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-220-2 | TO-220-2 |
| Supplier Device Package | TO-220AC | TO-220-2 |
| Operating Temperature - Junction | 150°C (Max) | -65°C ~ 175°C |
