| Part Number | 74LCX16821MEA | 74LCX16821MEAX |
|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor |
| Product Status | Obsolete | Obsolete |
| Function | Standard | Standard |
| Type | D-Type | D-Type |
| Output Type | Tri-State, Non-Inverted | Tri-State, Non-Inverted |
| Number of Elements | 2 | 2 |
| Number of Bits per Element | 10 | 10 |
| Clock Frequency | 150 MHz | 150 MHz |
| Max Propagation Delay @ V, Max CL | 6.2ns @ 3.3V, 50pF | 6.2ns @ 3.3V, 50pF |
| Trigger Type | Positive Edge | Positive Edge |
| Current - Output High, Low | 24mA, 24mA | 24mA, 24mA |
| Voltage - Supply | 2V ~ 3.6V | 2V ~ 3.6V |
| Current - Quiescent (Iq) | 20 µA | 20 µA |
| Input Capacitance | 7 pF | 7 pF |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | 56-SSOP | 56-SSOP |
| Package / Case | 56-BSSOP (0.295", 7.50mm Width) | 56-BSSOP (0.295", 7.50mm Width) |
