| Part Number | 2SK3821-E | 2SK3820-E |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Obsolete | Active |
| FET Type | N-Channel | - |
| Technology | MOSFET (Metal Oxide) | - |
| Drain to Source Voltage (Vdss) | 100 V | - |
| Current - Continuous Drain (Id) @ 25°C | 40A (Ta) | - |
| Drive Voltage (Max Rds On, Min Rds On) | 4V, 10V | - |
| Rds On (Max) @ Id, Vgs | 33mOhm @ 20A, 10V | - |
| Vgs(th) (Max) @ Id | 2.6V @ 1mA | - |
| Gate Charge (Qg) (Max) @ Vgs | 73 nC @ 10 V | - |
| Vgs (Max) | ±20V | - |
| Input Capacitance (Ciss) (Max) @ Vds | 4200 pF @ 20 V | - |
| FET Feature | - | - |
| Power Dissipation (Max) | 1.65W (Ta), 65W (Tc) | - |
| Operating Temperature | 150°C (TJ) | - |
| Mounting Type | Through Hole | - |
| Supplier Device Package | SMP | - |
| Package / Case | TO-220-3, Short Tab | - |
