| Part Number | 2SD1835T-AA | 2SD1835S-AA |
|---|---|---|
| Manufacturer | onsemi | Sanyo |
| Product Status | Obsolete | Active |
| Transistor Type | NPN | NPN |
| Current - Collector (Ic) (Max) | 2 A | 2 A |
| Voltage - Collector Emitter Breakdown (Max) | 50 V | 50 V |
| Vce Saturation (Max) @ Ib, Ic | 400mV @ 50mA, 1A | 400mV @ 50mA, 1A |
| Current - Collector Cutoff (Max) | 100nA (ICBO) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 100mA, 2V | 100 @ 100mA, 2V |
| Power - Max | 750 mW | 750 mW |
| Frequency - Transition | 150MHz | 150MHz |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | TO-226-3, TO-92-3 (TO-226AA) Formed Leads |
| Supplier Device Package | 3-NP | 3-NP |
