Please send RFQ , we will respond immediately.
| Part Number | 2SD1683S | 2SD1683T | 2SD1682S |
|---|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor | onsemi |
| Product Status | Obsolete | Obsolete | Active |
| Transistor Type | NPN | NPN | - |
| Current - Collector (Ic) (Max) | 4 A | 4 A | - |
| Voltage - Collector Emitter Breakdown (Max) | 50 V | 50 V | - |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 100mA, 2A | 500mV @ 100mA, 2A | - |
| Current - Collector Cutoff (Max) | 1µA (ICBO) | 1µA (ICBO) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 100mA, 2V | 200 @ 100mA, 2V | - |
| Power - Max | 1.5 W | 1.5 W | - |
| Frequency - Transition | 150MHz | 150MHz | - |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) | - |
| Mounting Type | Through Hole | Through Hole | - |
| Package / Case | TO-225AA, TO-126-3 | TO-225AA, TO-126-3 | - |
| Supplier Device Package | TO-126ML | TO-225-3 | - |
