| Part Number | 2SD1012G-SPA-AC | 2SD1012F-SPA-AC |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Obsolete | Obsolete |
| Transistor Type | NPN | NPN |
| Current - Collector (Ic) (Max) | 700 mA | 700 mA |
| Voltage - Collector Emitter Breakdown (Max) | 15 V | 15 V |
| Vce Saturation (Max) @ Ib, Ic | 80mV @ 10mA, 100mA | 80mV @ 10mA, 100mA |
| Current - Collector Cutoff (Max) | 1µA (ICBO) | 1µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 280 @ 50mA, 2V | 160 @ 50mA, 2V |
| Power - Max | 250 mW | 250 mW |
| Frequency - Transition | 250MHz | 250MHz |
| Operating Temperature | 125°C (TJ) | 125°C (TJ) |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | 3-SIP | 3-SIP |
| Supplier Device Package | 3-SPA | 3-SPA |
