Please send RFQ , we will respond immediately.
| Part Number | 2SC3332S-AA | 2SC3332T-AA | 2SC3332R-AA |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete |
| Transistor Type | NPN | NPN | - |
| Current - Collector (Ic) (Max) | 700 mA | 700 mA | - |
| Voltage - Collector Emitter Breakdown (Max) | 160 V | 160 V | - |
| Vce Saturation (Max) @ Ib, Ic | 400mV @ 2mA, 20mA | 400mV @ 25mA, 250mA | - |
| Current - Collector Cutoff (Max) | 100nA (ICBO) | 100nA (ICBO) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 100mA, 5V | 100 @ 100mA, 5V | - |
| Power - Max | 700 mW | 700 mW | - |
| Frequency - Transition | 120MHz | 120MHz | - |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | TO-226-3, TO-92-3 (TO-226AA) Formed Leads |
| Supplier Device Package | 3-NP | 3-NP | 3-NP |
