| Part Number | 2SC3332S | 2SC3382S | 2SC3332T | 2SC3330S | 2SC3331S | 2SC3332R |
|---|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Active | Obsolete | Active | Active | Obsolete |
| Transistor Type | NPN | - | NPN | - | - | - |
| Current - Collector (Ic) (Max) | 700 mA | - | 700 mA | - | - | - |
| Voltage - Collector Emitter Breakdown (Max) | 160 V | - | 160 V | - | - | - |
| Vce Saturation (Max) @ Ib, Ic | 400mV @ 25mA, 250mA | - | 400mV @ 25mA, 250mA | - | - | - |
| Current - Collector Cutoff (Max) | 100nA (ICBO) | - | 100nA (ICBO) | - | - | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 140 @ 100mA, 5V | - | 200 @ 100mA, 5V | - | - | - |
| Power - Max | 700 mW | - | 700 mW | - | - | - |
| Frequency - Transition | 120MHz | - | 120MHz | - | - | - |
| Operating Temperature | 150°C (TJ) | - | 150°C (TJ) | - | - | - |
| Mounting Type | Through Hole | - | Through Hole | - | - | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | - | TO-226-3, TO-92-3 (TO-226AA) | - | - | TO-226-3, TO-92-3 (TO-226AA) |
| Supplier Device Package | 3-NP | - | 3-NP | - | - | 3-NP |
