Please send RFQ , we will respond immediately.
| Part Number | 2SC3332R | 2SC3332S | 2SC3332T |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete |
| Transistor Type | - | NPN | NPN |
| Current - Collector (Ic) (Max) | - | 700 mA | 700 mA |
| Voltage - Collector Emitter Breakdown (Max) | - | 160 V | 160 V |
| Vce Saturation (Max) @ Ib, Ic | - | 400mV @ 25mA, 250mA | 400mV @ 25mA, 250mA |
| Current - Collector Cutoff (Max) | - | 100nA (ICBO) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | - | 140 @ 100mA, 5V | 200 @ 100mA, 5V |
| Power - Max | - | 700 mW | 700 mW |
| Frequency - Transition | - | 120MHz | 120MHz |
| Operating Temperature | - | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | TO-226-3, TO-92-3 (TO-226AA) | TO-226-3, TO-92-3 (TO-226AA) |
| Supplier Device Package | 3-NP | 3-NP | 3-NP |
