| Part Number | 2SA1943OTU | 2SA1943RTU |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Active |
| Transistor Type | PNP | PNP |
| Current - Collector (Ic) (Max) | 17 A | 17 A |
| Voltage - Collector Emitter Breakdown (Max) | 250 V | 250 V |
| Vce Saturation (Max) @ Ib, Ic | 3V @ 800mA, 8A | 3V @ 800mA, 8A |
| Current - Collector Cutoff (Max) | 5µA (ICBO) | 5µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 1A, 5V | 55 @ 1A, 5V |
| Power - Max | 150 W | 150 W |
| Frequency - Transition | 30MHz | 30MHz |
| Operating Temperature | -50°C ~ 150°C (TJ) | -50°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-264-3, TO-264AA | TO-264-3, TO-264AA |
| Supplier Device Package | TO-264-3 | TO-264-3 |
