| Part Number | 1N6270A | 1N6276A | 1N6274A | 1N6277A | 1N6271A | 1N6275A | 1N6272A | 1N6278A | 1N6279A | 1N6070A |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | onsemi | Solid State Inc. |
| Product Status | Active | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Active |
| Type | - | Zener | Zener | Zener | Zener | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | - | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Bidirectional Channels | - | - | - | - | - | - | - | - | - | - |
| Voltage - Reverse Standoff (Typ) | - | 13.6V | 11.1V | 15.3V | 8.55V | 12.8V | 9.4V | 17.1V | 18.8V | 160V |
| Voltage - Breakdown (Min) | - | 15.2V | 12.4V | 17.1V | 9.5V | 14.3V | 10.5V | 19V | 20.9V | 181V |
| Voltage - Clamping (Max) @ Ipp | - | 22.5V | 18.2V | 25.2V | 14.5V | 21.2V | 15.6V | 27.7V | 30.6V | 278V |
| Current - Peak Pulse (10/1000µs) | - | - | - | - | - | - | - | - | - | 5.4A |
| Power - Peak Pulse | - | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) |
| Power Line Protection | - | No | No | No | No | No | No | No | No | No |
| Applications | - | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - | - | - | - | - | - | - |
| Operating Temperature | - | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | -65°C ~ 175°C (TJ) | - |
| Mounting Type | - | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | - | DO-201AD, Axial | DO-201AD, Axial | DO-201AD, Axial | DO-201AD, Axial | DO-201AD, Axial | DO-201AD, Axial | DO-201AD, Axial | DO-201AD, Axial | DO-13 |
| Supplier Device Package | - | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | DO-13 |
