| Part Number | 1.5KE16AG | 1.5KE16AH | 1.5KE16A |
|---|---|---|---|
| Manufacturer | onsemi | Taiwan Semiconductor Corporation | Littelfuse Inc. |
| Product Status | Obsolete | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | 1 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 13.6V | 13.6V | 13.6V |
| Voltage - Breakdown (Min) | 15.2V | 15.2V | 15.2V |
| Voltage - Clamping (Max) @ Ipp | 22.5V | 22.5V | 22.5V |
| Current - Peak Pulse (10/1000µs) | 67A | 70A | 67.6A |
| Power - Peak Pulse | 1500W (1.5kW) | 1500W (1.5kW) | 1500W (1.5kW) |
| Power Line Protection | No | No | No |
| Applications | General Purpose | Automotive | General Purpose |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -65°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-201AD, Axial | DO-201AA, DO-27, Axial | DO-201AA, DO-27, Axial |
| Supplier Device Package | Axial | DO-201 | DO-201 |
