| Part Number | TDF8599ATH/N2,512 | TDF8599TH/N2,512 | TDF8599ATH/N2,518 |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| Type | Class D | Class D | Class D |
| Output Type | 1-Channel (Mono) or 2-Channel (Stereo) | 1-Channel (Mono) or 2-Channel (Stereo) | 1-Channel (Mono) or 2-Channel (Stereo) |
| Max Output Power x Channels @ Load | 250W x 1 @ 2Ohm; 135W x 2 @ 4Ohm | 85W x 1 @ 1Ohm; 70W x 2 @ 2Ohm | 250W x 1 @ 2Ohm; 135W x 2 @ 4Ohm |
| Voltage - Supply | 8V ~ 35V | 8V ~ 18V | 8V ~ 35V |
| Features | Depop, Differential Inputs, I²C, Mute, Short-Circuit and Thermal Protection | Depop, Differential Inputs, I²C, Mute, Short-Circuit and Thermal Protection | Depop, Differential Inputs, I²C, Mute, Short-Circuit and Thermal Protection |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Supplier Device Package | 36-HSOP | 36-HSOP | 36-HSOP |
| Package / Case | 36-BSSOP (0.433", 11.00mm Width) Exposed Pad | 36-BSSOP (0.433", 11.00mm Width) Exposed Pad | 36-BSSOP (0.433", 11.00mm Width) Exposed Pad |
