Please send RFQ , we will respond immediately.
| Part Number | TDA8566Q/N2C,112 | TDA8566Q/N2S,112 | TDA8566Q/N2,112 |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| Type | Class B | Class B | Class B |
| Output Type | 2-Channel (Stereo) | 2-Channel (Stereo) | 2-Channel (Stereo) |
| Max Output Power x Channels @ Load | 55W x 2 @ 2Ohm | 55W x 2 @ 2Ohm | 55W x 2 @ 2Ohm |
| Voltage - Supply | 6V ~ 18V | 6V ~ 18V | 6V ~ 18V |
| Features | Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby | Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby | Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Supplier Device Package | DBS17P | 17-PDBS | DBS17P |
| Package / Case | 17-SIP Formed Leads | 17-SIP Formed Leads | 17-SIP Formed Leads |
