| Part Number | PCA9554AD,112 | PCA9554ADB,112 | PCA9554AD,118 | PCA9554AN,112 | PCA9554D,112 |
|---|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Active | Obsolete | Obsolete |
| Number of I/O | 8 | 8 | 8 | 8 | 8 |
| Interface | I²C, SMBus | I²C, SMBus | I²C, SMBus | I²C, SMBus | I²C, SMBus |
| Interrupt Output | Yes | Yes | Yes | Yes | Yes |
| Features | POR | POR | POR | POR | POR |
| Output Type | Push-Pull | Push-Pull | Push-Pull | Push-Pull | Push-Pull |
| Current - Output Source/Sink | 10mA, 25mA | 10mA, 25mA | 10mA, 25mA | 10mA, 25mA | 10mA, 25mA |
| Clock Frequency | 400 kHz | 400 kHz | 400 kHz | 400 kHz | 400 kHz |
| Voltage - Supply | 2.3V ~ 5.5V | 2.3V ~ 5.5V | 2.3V ~ 5.5V | 2.3V ~ 5.5V | 2.3V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Through Hole | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | 16-SSOP (0.209", 5.30mm Width) | 16-SOIC (0.295", 7.50mm Width) | 16-DIP (0.300", 7.62mm) | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SO | 16-SSOP | 16-SO | 16-DIP | 16-SO |
