| Part Number | P2040NSN7MMC | P4040NSN7MMC | P2040NXN7MMC |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| Core Processor | PowerPC e500mc | PowerPC e500mc | PowerPC e500mc |
| Number of Cores/Bus Width | 4 Core, 32-Bit | 4 Core, 32-Bit | 4 Core, 32-Bit |
| Speed | 1.2GHz | 1.5GHz | 1.2GHz |
| Co-Processors/DSP | - | - | - |
| RAM Controllers | DDR3, DDR3L | DDR2, DDR3 | DDR3, DDR3L |
| Graphics Acceleration | No | No | No |
| Display & Interface Controllers | - | - | - |
| Ethernet | 10/100/1000Mbps (5) | 1Gbps (8), 10Gbps (2) | 10/100/1000Mbps (5) |
| SATA | SATA 3Gbps (2) | - | SATA 3Gbps (2) |
| USB | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) |
| Voltage - I/O | 1.0V, 1.35V, 1.5V, 1.8V, 2.5V, 3.3V | 1.8V, 2.5V, 3.3V | 1.0V, 1.35V, 1.5V, 1.8V, 2.5V, 3.3V |
| Operating Temperature | 0°C ~ 105°C (TA) | 0°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Security Features | - | - | - |
| Package / Case | 780-BFBGA, FCBGA | 1295-BBGA, FCBGA | 780-BBGA, FCBGA |
| Supplier Device Package | 780-FCPBGA (23x23) | 1295-FCPBGA (37.5x37.5) | 780-FCPBGA (23x23) |
