Please send RFQ , we will respond immediately.
| Part Number | P1015NXN5DFB | P1016NXN5DFB | P1025NXN5DFB | P1010NXN5DFB | P1014NXN5DFB | P1015NSN5DFB | P1015NXE5DFB | P1015NXN5BFB |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Core Processor | PowerPC e500v2 | PowerPC e500v2 | PowerPC e500v2 | PowerPC e500v2 | PowerPC e500v2 | PowerPC e500v2 | PowerPC e500v2 | PowerPC e500v2 |
| Number of Cores/Bus Width | 1 Core, 32-Bit | 1 Core, 32-Bit | 2 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit |
| Speed | 667MHz | 667MHz | 667MHz | 1.0GHz | 800MHz | 667MHz | 667MHz | 667MHz |
| Co-Processors/DSP | - | Communications; QUICC Engine | Communications; QUICC Engine | - | - | - | Security; SEC 3.3 | - |
| RAM Controllers | DDR3 | DDR2, DDR3 | DDR2, DDR3 | DDR3, DDR3L | DDR3, DDR3L | DDR3 | DDR3 | DDR3 |
| Graphics Acceleration | No | No | No | No | No | No | No | No |
| Display & Interface Controllers | - | - | - | - | - | - | - | - |
| Ethernet | 10/100/1000Mbps (3) | 10/100/1000Mbps (3) | 10/100/1000Mbps (3) | 10/100/1000Mbps (3) | 10/100/1000Mbps (2) | 10/100/1000Mbps (3) | 10/100/1000Mbps (3) | 10/100/1000Mbps (3) |
| SATA | - | - | - | SATA 3Gbps (2) | SATA 3Gbps (2) | - | - | - |
| USB | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (1) | USB 2.0 + PHY (1) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) |
| Voltage - I/O | - | - | - | - | - | - | - | - |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | 0°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Security Features | - | - | - | - | - | - | Cryptography, Random Number Generator | - |
| Package / Case | 561-FBGA | 561-FBGA | 561-FBGA | 425-FBGA | 425-FBGA | 561-FBGA | 561-FBGA | 561-FBGA |
| Supplier Device Package | 561-TEPBGA I (23x23) | 561-TEPBGA I (23x23) | 561-TEPBGA I (23x23) | 425-TEPBGA I (19x19) | 425-TEPBGA I (19x19) | 561-TEPBGA I (23x23) | 561-TEPBGA I (23x23) | 561-TEPBGA I (23x23) |
